Complete HDL Framework Panel System Layout 7. Includes the panels, connecting hardware and furniture listed for the selected configuration.
Grey woven fabric panels with charcoal powder-coated frames. Panels are tackable above work surface height. Clear glazed panels and plexiglass extensions are included only where listed.
Configuration A
| Item | Description | Quantity |
|---|---|---|
| FRM-7266P | 66” TALL PANEL | 2 |
| FRM-3666P | 66” TALL PANEL | 4 |
| FRM-2466P | 66” TALL PANEL | 1 |
| FRM-66SQP-3W | SQUARE 3 WAY CONNECTING POST | 1 |
| FRM-66SQP-2W | SQUARE 2 WAY CONNECTING POST | 2 |
| FRM-OS36 | OVERHEAD SHELF SET | 2 |
| FRM-OSC36 | OVERHEAD STORAGE CABINET | 2 |
| FRM-66PET | PANEL END TRIM | 3 |
| FRM-PCK | PANEL CONNECTING KIT | 2 |
| INV-7236CM | EXTENDED CORNER MODULE | 2 |
| INV-2436RSBR | RETURN SHELL/BRIDGE | 2 |
| INV-FPUF | FREESTANDING PEDESTAL - NO TOP | 2 |
| 100-AKTM-2 | ARTICULATING KEYBOARD TRAY | 2 |
Configuration B
| Item | Description | Quantity |
|---|---|---|
| FRM-7266P | 66” TALL PANEL | 2 |
| FRM-3666P | 66” TALL PANEL | 4 |
| FRM-2466P | 66” TALL PANEL | 1 |
| FRM-66SQP-3W | SQUARE 3 WAY CONNECTING POST | 1 |
| FRM-66SQP-2W | SQUARE 2 WAY CONNECTING POST | 2 |
| FRM-OS36 | OVERHEAD SHELF SET | 2 |
| FRM-OSC36 | OVERHEAD STORAGE CABINET | 2 |
| FRM-66PET | PANEL END TRIM | 3 |
| FRM-PCK | PANEL CONNECTING KIT | 2 |
| INV-362472ECM | 72” NON-HANDED EXTENDED CORNER MODULE | 2 |
| INV-2436TOP | 36” RECTANGULAR TOP | 2 |
| INV-FPUF | FREESTANDING PEDESTAL - NO TOP | 2 |
| 900-LOOP24 | 24” METAL LOOP LEG | 2 |
| 100-AKTM-2 | ARTICULATING KEYBOARD TRAY | 2 |
| 100-WSCK | WORKSURFACE CONNECTING KIT | 2 |
| FRM-WSMK | WORKSURFACE MOUNTING KIT | 4 |
| 100-WSB-64 | 64” STIFFENER BAR FOR USE W/ 72” TOPS | 2 |
Photos illustrate the arrangement; chairs, computers and decorative items are not included. Only the listed components are included. Assembly is required. Electrical accessories, delivery and installation are separate unless specified.
Furniture finish applies to Innovations laminate furniture; panels remain grey fabric with charcoal frames.
